Chapter 20: Carboxylic
Acid Derivatives |
|
Spectroscopic Analysis
of Esters
- IR - presence of
C=O, and two C-O bands (Csp2-O and Csp3-O bonds)
Absorbance (cm-1)
|
Interpretation
|
1735
|
C=O stretch
|
1300-1000
|
two bands for C-O stretch
|
- 1H
NMR - deshielded proton of H-C-O is often recognisable, and H-C-C=O.
Resonance (ppm)
|
Interpretation
|
3.5-4.5
|
H-COC
|
2-2.5
|
H-C-C=O
|
- 13C
NMR
C=O typically 160-180 ppm (deshielding due to O)
- minimal intensity, characteristic
of C's with no attached H's
- UV-VIS
two absorption maxima π→ π* (<200 nm) n→ π*
(~207 nm)
- π electron from π of
C=O
- n electron from O lone
pair
- π* antibonding
C=O
