Part 5: MECHANISMS

Note that no other reagents are needed in order to complete any of these sequences, you should only be using what is there.

General common errors:

(1) incorrect formal charges (2) backwards arrows (3) not showing the arrows for all the bonding changes (i.e. missing steps) (4) misuse of resonance / equilibrium arrows (5) vague arrows e.g. not starting where the electrons are i.e. on a bond or lone pair.
